Product feature:
● Defect automatic inspection
● Automatic measure length and width
● Automatic stick label
● Automatic edge alignment control
● Automatic score according America 4 point system
● Automatic generate report
Detectable defect type:
Snag, hole, flying catkins, warp breaks, creases, weft breaks, long warp and weft defects, stain, pinholes, color fiber, knot
Product advantages:
High recognition rate, reduce compensation:
Realize the full inspection of the whole roll fabric, the inspection rate is stable and higher than manual, which can reduce the compensation asked by the customer caused by random inspection and inaccurate inspection.
Improve the stability of production capacity:
Uninterrupted operation in 24hours, reducing the dependence on people, preventing production capacity fluctuations caused by staff leave or departures.
High efficiency, reduce labor:
It can replace 2-3 fabric inspectors and has low requirements for inspectors, save high labor cost every year.
Speed Detection:
Traditional fabric inspection speed is about 15m/min (whole fabric inspection), AI fabric inspection machine max. inspection speed is 40m/min
Informatization and digitization:
Open API interface, connect with ERP, MES and other system, can connect with automatic equipment or manager computer.
Specification:
| Model | YL-2021AI | Fabric working width | 2100mm |
| Voltage | AC 1PH 220V 50HZ | Labeling position | ±6cm |
| Rated Power | 4.5Kw | Fabric working diameter | 40cm |
| Defect inspection rate | ~75%(Visible defect to the naked eye) | Length measurement deviation | ≤0.5% |
| Inspection rate | Max. 40m/min(not include labeling time) | Width detect deviation | ±2cm |
| Detection precision | Max.5mm |
